Galden HT 230

SKU: HT230

This PFPE fluid is suitable for heat transfer applications. The fluid is suitable for extreme temperatures and nonflammable.

Benefits Galden HT 230

  • High thermic stability
  • Nonflammable
  • High dielectric strength
  • No auto-ignition point
  • Description
  • Product information
  • Industries
  • Downloads

Galden HT 230

Galden HT 230 has an extremely high boiling point of 230°C. This in combination with its chemical inertness makes the heat transfer fluid extremely suitable for applications in the semiconductor, chemical and pharmaceutical industries, among others.

Product features Galden HT 230

  • Non toxic
  • Compatible with metals, elastomers and plastics
  • Chemically inert
  • Low evaporation loss
More information

Galden HT 230

Base fluid

PFPE

Boiling point

230 °C

Density

1.82 g/cm3

Viscosity at 25°C

4.40 cSt

Vapor pressure at 25°C

0.025 torr

Specific heat

0.232 cal/g °C

Surface tension

19 dyne/cm

Dielectric strength

40 kV (2.54 mm gap)

Dielectric constant

1.94

Volume resistivity

6 ∙ 10 15 Ohm-cm

Molecular Weight

1020 amu

Solubility of water

<10 ppm

Packaging

5 KG

Available in

Worldwide

Industry

Electronics and Semiconductor
